What is the iJewel Rhino Plugin?
The iJewel Rhino Plugin is a free command that iJewel3D publishes for Rhino. It sends the model open in Rhino to iJewel3D, and it runs inside any Rhino-based jewelry app.
Rhino 8
Rhino models in iJewel3D
One command in Rhino opens your model in iJewel3D, where you set materials, capture images, and send a client link.
Why connect it to iJewel3D
A Rhino file needs Rhino to open, and a still render answers only one view of the piece. iJewel3D publishes the same model to a browser link that a client opens on any device.
Key Features
Export with one command
Run iJewelPlatform in the Rhino command line to send the open model.
Publish to your organization
Run iJewelEnterprise to send the model straight to your own iJewel3D drive.
Share a live link
Send clients a browser link that opens the model on phone, tablet or desktop.
How It Works
1
Model in Rhino
Build the piece in Rhino or in any Rhino-based jewelry app.
2
Name your layers
Name layers Metal or Gem so the plugin assigns the right materials.
3
Run the export command
Type iJewelPlatform in the Rhino command line and press Enter.
4
Present in iJewel3D
Set materials, capture images and send the client an interactive link.
Installation Guide
1
Open the Rhino Package Manager
Click the button below to open the package manager in Rhino.
Open in Package ManagerYou can also type PackageManager in the Rhino command line, or use the menu path Tools → Package Manager. Then search for iJewelViewer.
The plugin is also available on Food4Rhino.
2
Install the plugin
Click Install in the Package Manager, then restart Rhino so the plugin loads.
3
Verify the installation
Type one of the export commands in the Rhino command line:
iJewelPlatform
iJewelEnterprise (for organizations)
If Rhino recognises the command, the plugin is installed.
Connect with Organization
If your team has an iJewel3D organization, send exports straight to it with the iJewelEnterprise command.
1
Run the enterprise command
Type iJewelEnterprise in the Rhino command line and press Enter.
2
Enter your organization name
At the Enter your drive name prompt, type the name from your URL. For https://ijewel3d.com/mydrive, enter mydrive.
3
Log in and save
The plugin exports the current model and opens the Playground in your organization. You keep your own settings, and files save to your own drive.
Works with your jewelry apps
The plugin is a standard Rhino command, so it runs from the command line inside any Rhino-based jewelry environment, not only in plain Rhino.
Troubleshooting
Rhino does not recognise the command+
Restart Rhino after the install. If Rhino still does not recognise the command, reinstall the plugin from the Package Manager.
Materials look wrong after the export+
The plugin exports geometry only. Name your Rhino layers Metal or Gem, then set the final materials in the iJewel3D editor.
Requirements
- CAD host
- Rhino 8
- Commands
- iJewelPlatform, iJewelEnterprise
- iJewel account
- Free account for iJewelPlatform
- Organization
- iJewelEnterprise needs an organization plan
- Cost
- No charge for the plugin
Verified against the iJewel3D Rhino plugin documentation, 31 August 2026.
What it does not do
- ✓Modeling and geometry edits stay in Rhino.
- ✓The plugin exports geometry; you apply materials in iJewel3D.
- ✓Rhino render settings do not transfer. iJewel3D uses its own environments.
- ✓Manufacturing stays with your existing supplier.
FAQ
Which versions do I need?+
The plugin runs on Rhino 8. Install it from the Rhino Package Manager or from Food4Rhino.
Where is the command in Rhino?+
There is no button. Type iJewelPlatform in the Rhino command line, or iJewelEnterprise for an organization drive.
Do I need an iJewel3D account?+
Yes. A free iJewel3D account covers iJewelPlatform. iJewelEnterprise needs an iJewel3D organization plan.
Does it cost extra?+
No. The plugin is free. Paid iJewel3D plans add storage, organization drives and white-label options.
Does iJewel3D replace Rhino?+
No. Rhino stays the CAD tool. iJewel3D presents the finished model and shares it with clients.
Where do I get help?+
Join iJewel3D on Discord or email contact@ijewel3d.com. For Rhino itself, contact McNeel support.
Get Started
Install the plugin from the Rhino Package Manager, then run iJewelPlatform on your next model.
Need help? Join iJewel3D on Discord, or email contact@ijewel3d.com.
